Place of Origin: | CHINA |
Brand Name: | NANTE |
Certification: | ISO, CE, CCC |
Model Number: | F21-E2B Series |
Minimum Order Quantity: | 1 |
---|---|
Packaging Details: | Seaworthy Packing |
Delivery Time: | According to customer's requirements |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
Supply Ability: | 500000 Piece/Pieces per Year |
Model Number:: | F21-E2B | Use:: | Universal |
---|---|---|---|
Weight:: | Approx.295g | Speed:: | Single |
Shell:: | Fiberglass | Dimension:: | 165*75*45 |
Control Distance:: | Within 100m | ||
High Light: | hoist push button switch,Crane Remote Control |
1. Industrial Wireless Remote Controls Power Switch , 6 Step Pushbuttons
2. Single speed available
Keypad, Crane Push Button
IP65 Crane Digital industrial Wireless Remote Control , DC 12 / 24
Design features
1 |
• 2~6 commands (Pocket size transmitter : F21-E2B) |
2 |
• Low cost for electronic chain hoist/monorail |
3 |
• Low power consumption transmitter. 2 AA batteries last up to 4 months |
4 |
• Extra shock resistant relay specially for mobile devices .(DC model only) |
5 |
• Over 4.3 billions unique ID code available. |
6 |
• Temperature range -35°C ~ +85°C |
7 |
• Enclosure protection class IP 65 |
8 |
• Microsoft Windows based software for easy customize configuration |
9 |
• Structure : Glass-Fiber |
Dimension
165*75*45
Button
6 button, 1 step, 1 EMS
Weight
Approx. 295g (including batteries)
Receiver
1 |
• Dimension: 200x85x60mm |
2 |
• Weight: 785g-805g (including batteries) |
3 |
• Receiver Power Supply: 24/48/110/220/380 VAC & 12/24V DC |
Detailed Product Description
Auto Frequency Selection
Chooses top grade RF 1C with sophisticated design. It provides great performance on radio channel selectivity.
Real time frequency changing technology which provides the best operating experience and free from interference.
No channel changing required when multiple radio controllers are used at the same time.
Radio Frequency Filtering
A sophisticated Surface Acoustic Wave (SAW filter blocks unwanted radio signal to ensuresmooth radio link.
It creates a secure and reliable operation experience even in a complicated industrial working environment
Reliable Communication
F21-E2B, a smart radio controller made by high technology.
100% frequency quality inspection on all radio controllers prior to delivery and ensure frequency tolerance within 0.000001%.
6-Card (Plug and Play)
E-Card works similar to SIM card in the mobile phone.
All system data are carried on a small e-Card for easy transfer to a spare system when needed.
E-Card is interchangeable between transmitter & receiver. It allows spare transmitter or receiver to resume to work without any downtime.
6-Card Duplicator
The transmitter also acts as e-Card duplicator for data back-up and transfer, i No need to buying COPIER anymore.
Specifications
Low power consumption transmitter
Over 4.3 billions unique ID code available
Microsoft Windows based software
Application
The ranges of applications of our industrial radio remote control system
1. overhead bridge cranes,
2. gantry crane
3. beam launcher
4. monorail hoists,
5. motorized jib cranes o
6. Other pieces of industrial equipment.
Budget & Environmental Saving
Transmitter with extremely low battery power consumption.
All F21-E2B series transmitters use two AA size batteries.(Carbon Zinc,Alkaline,Ni-MH,Ni-Cd are all acceptable)
You can also select operating range:
FREE Powerful Software Program
Free software consists millions worldwide users' experience.
F21-E2B software is the total solution for industrial remote controller.
The software provides great flexibility to meet most of the applications. It allows reprogramming numbers of parameters such as operation function, emission power, and receiver off time, etc.
Software features
The software provides great flexibility to meet most of the applications. It allows reprogramming numbers of parameters such as pushbutton function mode (Normal, Toggle, Magnet ON/OFF), Interlock Start Alarm, Selectable Emission Power, and Receiver Auto -Off Time, etc.
Security Enhanced & Anti-Spy
Heavy Duty
Pushbutton key acts as important role for industrial remote controller.F21-E2B uses a super heavy-duty pushbutton against all severe conditions.
