Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg

Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg

    • Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg
    • Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg
  • Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg

    Product Details:

    Place of Origin: CHINA
    Brand Name: NANTE
    Certification: ISO9000
    Model Number: W45AMC-150

    Payment & Shipping Terms:

    Minimum Order Quantity: I SET/SETS
    Packaging Details: Naked, Wooden case or Carton
    Delivery Time: 15 working days after received your payment
    Payment Terms: L/C, D/A, D/P, T/T, Western Union
    Supply Ability: 2000000 Piece/Pieces per Year
    Contact Now
    Detailed Product Description
    Bearing:: Ball Bearing Material: Galvanized Steel
    Travel Speed: <250m/min Bumper: Neoprene
    Weight: 2.45kg Cable Load: Max.60kg
    Temperature: -30℃ To +120℃ Place Of Origin:: Zhejiang, China (Mainland)
    High Light:

    I Beam Festoon System

    ,

    h Beam Trolley

    I Beam Festoon System for Crane, H-Beam Festoon Cable Trolley, I Beam and Trolley, Stretched Wire Festoon System, I Beam Cable Carrier Large Round/Flat Cable, Festoon Cable System.

    Place of Origin: Zhejiang, China (Mainland)
    Brand Name: Nante
    Model Number: W45AMC-150
    Material: Galvanized steel
    Bearing: Ball bearing
    Travel Speed: <250m/min
    Temperature: -30℃ to +120℃
    Cable Load: Max.60kg
    Weight: 2.45kg
    Bumper: Neoprene

    Packaging & Delivery

    Packaging Details: Naked, Wooden case or Carton
    Delivery Detail: Within 15days

    Specifications

    1. Anti-explosion Festoon Cable Trolley on I Beam
    2. Delivering power&control to mobile equipment





    Detailed Product Description



    Anti-explosion Festoon Cable Trolley on I Beam, I Beam Festoon System for Crane, H-Beam Festoon Cable Trolley, I Beam and Trolley, Stretched Wire Festoon System, I Beam Cable Carrier Large Round/Flat Cable, Festoon Cable System.



    Detailed Product Description

    This series of I beam trolleys and components integrating our worldwide job proven flat cable provides a safe, efficient and maintenance free method of mobile electrification. The minimum bending radius permissible for lat cable is 5 times the thickness of the cable, thus allowing a considerably smaller bend radius compared to round cable of equal conductor size.



    Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg 0

    Application

    Crane manufacturing, hoist units, transport systems, special engineering, stacking systems, conveyor system, etc. C-rails are available in zinc-coated and stainless steel version (program 230 to 240). Special versions are available for explosion-proof areas.





    Design features:

    Compact arrangement, elegent appearance.

    Corrosion resistance

    Simple assembly

    Easy for transportation and installation





    Technical Parameters



    Type W35MC-70 W35MC-120 W35MC-150
    Wheels Ball bearings, hardened, galvanized                           Temperature resistance: -30C to +120C
    Travelling speed: ca. 300 m/min.
    Material Carrier body: steel, galvanized       Support saddle: steel, galvanized       Bumper: Neoprene
    Dowel: steel, galvanized                 Hardware: galvanized
    Temperature resistance: -30°C to +120°C
    Max. cable load max.50KG max.60KG max.70KG
    Dim. of Cable (mm) max.75 Wx32δ max.120 Wx60δ max.150 Wx70δ
    Weight(kg) 1.9 2.4 2.5
