Crane Radio Remote Control Overhead Crane Controls For Beam Launcher

Crane Radio Remote Control Overhead Crane Controls For Beam Launcher

    • Crane Radio Remote Control Overhead Crane Controls For Beam Launcher
    • Crane Radio Remote Control Overhead Crane Controls For Beam Launcher
  • Crane Radio Remote Control Overhead Crane Controls For Beam Launcher

    Product Details:

    Place of Origin: CHINA
    Brand Name: NANTE
    Certification: ISO, CE, CCC
    Model Number: F23

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Packaging Details: According to customer's requirements
    Payment Terms: L/C, D/A, D/P, T/T
    Supply Ability: 500000 Piece/Pieces per Year
    Contact Now
    Detailed Product Description
    Brand Name:: Nante Model Number:: F23
    Use:: Universal Shell:: Fiberglass
    Control Distance:: Within 100m Speed:: Double/Single
    High Light:

    hoist push button switch

    ,

    Crane Remote Control

    Specifications

    1. F23-A Wireless Hoist Remote Control Digital Radio Glass-fiber IP 65
    2. Single/double speed available



    F23 A+ Crane Remote Control Industrial Wireless Remote Control, DC 12/24/48V, Wireless Industrial Crane Remote Control Keypad, Crane Push Button



    Crane Radio Remote Control Overhead Crane Controls For Beam Launcher 0

    Crane Radio Remote Control Overhead Crane Controls For Beam Launcher 1

    Detailed Product Description

    Radio Remote Controls have become a key element within a modern working context where safety, productivity, freedom of movement has a continuously increasing importance. Industrial radio controllers

    are consequently for time saving and risk reduction working instruments.

    Thanks to the radio controller, the operator stands in the place with the best visibility and lowest operation risk. The wireless technology allows controlling the machine in full autonomy without requiring

    other operators to support the job with indications.

    AN INDUSTRIAL RADIO REMOTE CONTROL DIFFERS FROM COMMON WIRELESS CONTROLLERS IN DESIGN AND MANUFACTURING ASPECTS LIKE:



    EXCLUSIVE CONTROL

    You will be certain that no other radio device will take over the control of your application thanks to an exclusive communication channel protected by a unique ID code that IMET assigns to each radio



     remote control.



    CONTINUOUS AND SAFE TRANSMISSION

    This device operates in continuous transmission between the transmitting and receiving units. The radio link is made of digital communication frames that are monitored by algorithms at the reception.

     This guarantee an absolute correspondence between the commands sent by the operator and the received commands. When the radio link is too disturbed or interrupted the receiver unit will autonomously

     turn into Stop mode bringing the machine to a safe status.



    INTRINSIC SELF CONTROL

    Our Radio controllers are based on designing and manufacturing concepts aiming to guarantee safety and reliability. For example, the CPU features dual microprocessors in cross checking, STOP

     circuit is made of monitored double safety relays, STOP relay is available for the reduction of motion command failure risk, error and failure test are performed at each transmitter and receiver powering.



    Application

    The ranges of applications of our industrial radio remote control system

    1. overhead bridge cranes,
    2. gantry crane
    3. beam launcher
    4. monorail hoists,
    5. motorized jib cranes
    6. Other pieces of industrial equipment.





    Design features

     • 6 ~10 commands, Rotary Key Switch + EMERGENCY-STOP
     • Transmitter Power supply: 2 AA Alkaline batteries.
     • Over 4.3 billions unique ID code available
     • Hamming code & enhanced safety watch-dog circuit
     • Internal antenna for both transmitter & receiver (Option:
       Receiver external passive antenna available)
     • Operating temperature range -35°C to +85°C
     • Enclosure protection class IP 65
     • Microsoft Windows based software for easy customize
       configuration
     • Easy customization

     • Structure : Glass-Fiber
