Construction Electric Wire Rope Hoist Wire Rope Pulling Hoist 440V/380V

Construction Electric Wire Rope Hoist Wire Rope Pulling Hoist 440V/380V

    • Construction Electric Wire Rope Hoist Wire Rope Pulling Hoist 440V/380V
    • Construction Electric Wire Rope Hoist Wire Rope Pulling Hoist 440V/380V
  • Construction Electric Wire Rope Hoist Wire Rope Pulling Hoist 440V/380V

    Product Details:

    Place of Origin: Zhejiang,China
    Brand Name: NANTE
    Certification: ISO9001, CE
    Model Number: SHA-XD

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Packaging Details: Plywood Packing
    Delivery Time: Within 50 days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union
    Supply Ability: 10000 Piece/Pieces per Year
    Contact Now
    Detailed Product Description
    Model Number:: Hoist Brand Name:: Nante
    Place Of Origin:: Zhejiang, China (Mainland) Usage:: Construction Hoist, Mining, Oil, Petrochemical, Etc Type
    Sling Type:: Wire Rope Power Source:: Electric
    High Light:

    low headroom trolley hoist

    ,

    Industrial Electric Hoist

    Electric Wire Rope Pulling Hoist Low Headroom 440V/380V for I Beam

    Quick Details

    • Condition: New
    • Place of Origin: Zhejiang, China (Mainland)
    • Brand Name: Nante
    • Model Number: SHA
    • Usage: Construction Hoist
    • Power Source: Electric
    • Sling Type: Wire Rope
    • Maximum Lifting Weight: 12.5ton
    • Maximum Lifting Height: 30m
    • Lift Speed: 8/1.2m/min
    • Certification: ISO, CE, CCC
    • Warranty: 12 month
    • Housing: Tailor-made strengthened profile
    • Driving system: Three-in-one
    • Track type: H beam, box girder, I beam
    • Wire rope strength: 2160kn/mm

    Packaging & Delivery

    Packaging Details: Plywood package
    Delivery Detail: Within 50 days

    Specifications



    1. Electric Wire Rope Pulling Hoist Low Headroom 440V/380V for I Beam
    2. Usage: Material handling, metallurgy, etc
    3. Efficient, low cost



    Electric Wire Rope Pulling Hoist Low Headroom 440V/380V for I Beam, Low Hea

    droom Wire rope hoist, steel rope hoist, monorail hoist trolley.



    CE Certified Monorail Steel Rope Hoist Hoisting Machine, Workstation Wire Rope Hoist SHA-XD, steel rope hoist, monorail hoist trolley.







    Detail Product Description







    Low Headroom Electric Wire Rope Hoist is the newly developed type which is specific to the box type beam but not the traditional I beam. You can benefit from shock absorption and noise reduction. What’s more, the distance for the gauge can be adjusted. This products, by its newly unique design and great originality, have gained a good reputation among users in China and abroad.







    1. Reducer
    Third-class dead axel helica gear transmission structure is adopted,; gear and gear axel are made of heat treated alloy steel.



    2. Control Box
    It has device with up an down stroke protection of break off limiter and can cut off main circuit in an emergency,which ensures safe operation of electric block.Electric elements are of long service life and operational safety.



    3.Steel Wire Rope
    It uses GB1102-74(6*37+1) hoist steel wire rope which is durable in use.



    4. Conical Motor
    The hoist motor uses conical motors of relatively stronger starting torque to brake asynchronous motor and does not need extra arrester. The motor s load duration factor is 25%.



    5. Button Switch
    Its hand-operated, easy to handle,and has two modes of cord operation and cordless remote control




    6.Gear



    By adopting Japanese technology, they are innovated symmetrical arrayed high-speed synchronous gears, and are made from international standard gear steel.



    7.Chain



    Adopts high strength chain and high precision welding technology,meet ISO3077-1984 international standard;fits for gusty overload work conditions;takes your hands a better feeling multi-angle operation.



    8.Hook



    Made of high-class alloy steel,it has high strength and high security; by using new design, weight will never escape.







    Application







    Used in the factory, mine, dock, warehouse, temperature-20 ~ + 40 °C, relative humidity under 85%.







    Design Feature







    (1) imported motor can be chosen for high working level up to M5, low noise
    (2) applies to factories, freight yards, terminals, power plants, construction sites and other places
    (3) Particularly suitable for the plant with restrict height, maximize the effective lifting height







    General Drawing



     Construction Electric Wire Rope Hoist Wire Rope Pulling Hoist 440V/380V 0Construction Electric Wire Rope Hoist Wire Rope Pulling Hoist 440V/380V 1




    Technical Data







    Model Lifting
    Capacity
    (t)
    Lifting
    Speed
    (m/min)
    Travelling
    Speed
    (m/min)
    Working
    Duty
    Fall Lifting
    Motor
    Power(kw)


    C A1 A2 B Hmin
    SH A2XD 1.6 8.0/1.2 15.8/5 M5 2/1 2.5/0.37 100-400 420 320 590 570
    3.2 4.0/0.6 15.8/5 M5 4/1 2.5/0.37 100-400 420 320 436 500
    SH A3XD 2.5 8.0/1.2 15.8/5 M5 2/1 4.9/0.8 100-450 500 400 600 720
    5 4.0/0.6 15.8/5 M5 4/1 4.9/0.8 100-450 500 400 600 650
    SH A4XD 6.3 10/1,6 15.6/5 M4 2/1 12.5/2.0 100-500 570 500 700 950
    12.5 5.0/0.8 15.6/5 M4 4/1 12.5/2.0 100-500 570 500 700 800







    Model S L Self
    Weight
    (kg)
    6H 9H 12H 18H
    SH A2XD 0.0198H 690 810 925 1143
    0.0198H 925 1142 1381
    SH A3XD 0.0212H 720 845 972 1226
    0.0212H 972 1153 1392
    SH A4XD 0.0192H 761 881 993 1224
    0.0192H 993 1224 1455
