    Product Details:

    Place of Origin: CHINA
    Brand Name: Nante
    Certification: CE ISO
    Model Number: C32

    Payment & Shipping Terms:

    Minimum Order Quantity: 1meter
    Price: Nogetiable
    Packaging Details: Plywood case
    Delivery Time: within one week receiving payment
    Payment Terms: L/C, T/T
    Supply Ability: 1000000meter/year
    Contact Now
    Detailed Product Description
    Material: Galvanized Steel/Stainless Steel Bearing: Ball Bearing
    Temperature: -40~+125℃ Cable Load: <120Kg
    Travel Speed: <120m/min Weight: 1.19Kg
    High Light:

    c rail festoon system

    ,

    festoon cable systems



    Technical Data:




    Factory Workshop Festoon System For Overhead Crane Cable Roller 0Factory Workshop Festoon System For Overhead Crane Cable Roller 1Factory Workshop Festoon System For Overhead Crane Cable Roller 2

    Factory Workshop Festoon System For Overhead Crane Cable Roller 2



    Type C32*30*1.5 C40*40*2.0 C63*63*4.0 C30*28*1.5
    Material Galvanized steel / Except C63
    Weight kg/m 1.19 2.00 5.98 1.03
    Technical data
    A 32 40 63 30
    B 30 40 63 28
    C 12 13 18 10
    6 1.5 2.0 4.0 1.5
    Spacing Max. Cable Load
    1.5m 89kg 188kg 503kg 70kg
    2.0m 51kg 103kg 425kg 36 kg
    2.5m 39kg 73kg 302kg 22kg
    3.0m 23kg 49kg 195kg -
    4.0m - 28kg 85kg -





    Type Towing Trolley End Trolley Middle Trolley Round Cable Trolley
    Wheels

    Ball bearings, hardened, galvanized

    Temperature resistance Lub. grease of wheels: -30°C to +125°C

    Max. travelling speed: 160m/min.

    Ball bearings, hardened, galvanized

    Temperature resistance Lub. grease of wheels: -30°C to +125°C

    Travelling speed: ca 120m/min.

    Material

    Carrier body: steel, galvanized
    Support saddle: steel, galvanized
    Bumper: neoprene
    Dowel: brass
    Hardware: galvanized

    Temperature: resistance: -30°C to +100°C(ABS Saddle 80°C)

    Carrier body: steel, galvanized
    Clamp: steel, galvanized
    Sling: nylon
    Dowel: brass
    Hardware: galvanized
    Max. cable load Max. 25kg per carrier Max. 25kg per carrier Max. 30kg per carrier Max.22kg per carrier
    Dim. Of cable (mm) Max. 75w×32δ Max. 75w×32δ Max.75w×32δ Max. D=50mm/D=80mm/D=160mm
    Weight (kg) 0.61 0.39 0.415 0.29





    C Track Festoon System for Crane, Galvanized Steel Conductor Rails With Brass Dowel , C Rail and Trolley, Stretched Wire Festoon System, Festoon Cable Trolley, Festoon Cable System.



    Detailed Product Description

    Festoon System can hold conductor cables and hoses (hydraulic and pneumatic applications) for delivering power & control to mobile equipment in a safe, efficient and maintenance free method.

    The C-track system is one of the most versatile festooning techniques available. It is an all-purpose system suited for either indoor or outdoor use under a broad range of operating conditions in a mild environment condition.



    Application

    C-rail systems applications: crane manufacturing, hoist units, transport systems, special engineering, stacking systems, conveyor system, etc. C-rails are available in zinc-coated and stainless steel version (program 230 to 240). Special versions are available for explosion-proof areas.



    Design features:

    Compact arrangement, corrosion resistance and simple assembly are its essential features. Easy for transportation and installation. All accessory well included for customer.



    Factory Workshop Festoon System For Overhead Crane Cable Roller 4
