High Efficiency 0.5 Ton / 1 Ton Electrical Wire Rope Hoist For Mining / Factory / Dock

High Efficiency 0.5 Ton / 1 Ton Electrical Wire Rope Hoist For Mining / Factory / Dock

High Efficiency 0.5 Ton / 1 Ton Electrical Wire Rope Hoist For Mining / Factory / Dock

Product Details:

Place of Origin: CHINA
Brand Name: NANTE
Certification: ISO9001, CE, CCC
Model Number: Electric Wire Rope Hoist

Payment & Shipping Terms:

Minimum Order Quantity: 1 Piece/Pieces
Packaging Details: Plywood Packing
Delivery Time: Within 50 days
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 10000 Piece/Pieces per Year
Contact Now
Detailed Product Description
Model Number:: SH Usage:: Construction Hoist
Control Type:: Pendent Control, Remote Control Track Type:: H Beam, Box Girder, I Beam
Housing:: Tailor-made Strengthened Profile Lift Speed:: 7.5/2.0m/min
Power Source:: Electric, 3P, 380V, 50HZ, Other Type Also Available

Specifications



1. Wire Rope Electric Hoist For Mining, Factory, Dock
2. Usage: Material handling, metallurgy, etc
3. high efficiency




Wire Rope Electric Hoist For Mining, Factory, Dock

Steel rope hoist, quadrate style wire rope hoist, standard headroom rope hoist, standard headroom trolley hoist.



Detailed Product Description



STANDARD HEADROOM TROLLEY HOIST adopts the planetary gear reducer to ensure high transmission efficiency. It is characterized by low noise, compact structure, omitting the intermediate shaft. The square appearance is easier to install and fix.

The lifting hook is designed to prevent accidental slippage; Motor has the thermal protection device, which will automatically cut off to prevent damage when the temperature is too high, the machine uses cam limit at both ends to insure precision.

High safety and reliability is secured by our load limit protection device, which can avoid overload-induced adverse consequences.





Wire Rope Hoist



1. Hooks

Load hooks are heat treated and fracture resistant. In case of dangerous overloading or abuse, the hook does not fracture but will slowly yield.

2. Power

Operating voltage 220-440V, 50/60Hz, 1-3 phase.

Low voltage control 36V is standard.

Dual voltage is available.

3. Motor

High efficient energy-saving motor, asbestos free brake system. 2-speed motor available.

Sturdy pole change motors with cylindrical rotors and integrated safety brakes.

3. Limit Switch

Limit switch devices fitted at both top & bottom ends, switch off power automatically to prevent load chain from running out.

4. Pushbutton Swith

Pushbutton swith is rain-proof plastic for severe impact and corrosive atmosphere resistance and mechanically interlocked.

5. Hoisting Gear

Lightweight gear units with silent running flat bevelled gears deliver the torque required.

6.Rope guide

The rope guide reduces wear on the rope and rope drum. It is also easy to install, reducing maintenance requirements for the unit as a whole.





Application



Used in the factory, mine, dock, warehouse, steel mill, etc. Temperature-20 ~ + 40 °C, relative humidity under 85%.





Design Feature



  • SH series wire rope hoist, adopts the latest design of quadrate style
  • Modular design, good unitized capacity, enables diversified transformation of fundamental mode
  • Unique drive layout type, completely abandon the traditional form of the long drive shaft, realize extremely smooth transmission
  • Planetary reduction drive, high efficiency, low noise, longer life
  • Original cylindrical rotor - cone brake wheel motor, low noise, reliable braking
  • introducing foreign advanced rope guide, reliable performance
  • Advanced mechanical rotary limit switch, high accuracy
  • Electrical components with high quality control
  • Low failure rate
  • Full-scale capacity range from 400kg-50000kg
  • Fully comply with the newly international standards.
  • Electrical components with high quality control

Technical Parameter for STANDARD HEADROOM TROLLEY HOIST SH



Model Lifting
Capacity
(t)
Working
Duty
Lifting
Motor
Power(kw)


Lifting
Speed
(m/min)
Dimension L
6m 9m 12m 18m 24m 30m
SH2A(2/1) 0.5 M4 1.1
1.1/0.3
9
9/2.2
L 534 661 678 813 948 1083
LO 223 291 358 493 628 763
S 66 99 132 198 264 330
SH3A(2/1) 1 M4 1.5
1.5/0.4
8.5
8.5/3.2
L 886 983 1080 1274 1468 1662
LO 324 421 518 712 906 1100
S 96 144 192 288 384 480
SH4-2/1A 2 M4 3
3/0.8
7.3
7.3/1.8
L 1032 1136 1240 1449 1657 1866
LO 389 493 597 806 1014 1223
S 104 156 209 313 417 521
SH5-2/1A 3 M4 4.5
4.5/1.0
7
7/1.6
L 1160 1279 1379 1597 1815 2033
LO 414 524 633 851 1069 1287
S 110 164 219 328 437 546
SH6-2/1A 5 M4 7.5
7.5/2.0
7.3
7.3/1.8
L 1235 1350 1464 1693 1922 2151
LO 459 574 688 917 1146 1375
S 118 177 236 354 472 590
SH7-2/1A 8 M4 13
13/3.2
8
8/2
L 1473 1590 1706 1939 2172 2405
LO 505 622 738 971 1204 1473
S 117 175 233 350 466 583



Model A AO B Hmin L1 Wheel
Diameter
(mm)
SH2A(2/1) 256 192 244 410 281 13
SH3A(2/1) 264 194 244 430 390 18
SH4-2/1A 325 245 300 520 462 18
SH5-2/1A 360 280 335 600 550 18
SH6-2/1A 403 309 370 700 550 22
SH7-2/1A 470 350 440 760 725 26
