IP65 Industrial Remote Pendant Control Stations Plastic For Crane

Certification
Good quality Electric Chain Hoist for sales
Good quality Electric Chain Hoist for sales
I'm Online Chat Now

IP65 Industrial Remote Pendant Control Stations Plastic For Crane

China IP65 Industrial Remote Pendant Control Stations Plastic For Crane supplier

Large Image :  IP65 Industrial Remote Pendant Control Stations Plastic For Crane

Product Details:

Place of Origin: CHINA
Brand Name: NANTE
Certification: ISO9001, CE, CCC
Model Number: COBP

Payment & Shipping Terms:

Minimum Order Quantity: 1 Piece/Pieces
Packaging Details: Cartons
Delivery Time: Within 7 days
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 10000 Piece/Pieces per Year
Detailed Product Description
Electric Rating:: AC50/60Hz, AC400V/DC230V Color:: Yellow Or Optioal
Speed:: Single Speed Or Double Model Number:: AS
Use:: Universal Standard:: IEC 60947-5-1, EN 60947-5-1

Remote control, hoist switch, crane switch, crane push button, hoist station, pendant control station, push button for hoist and crane, push button switch for hoist and crane. Pendant crane control station switch

Supplier Crane Pendent Control Push Buttom Wireless Keypad ABS EN 60947-5-1,Single/double speed available





Description



Switch adopts high-quality engineering plastics, shell material is enhanced for anti-collision, and with lightweight; electrical contact is copper-based conductive, contact surface is silver-nickel alloy material, enhancing the contact capacity and control system stability in week power control system. Waterproof seals and silica gel cable sheath in inside for a better dustproof and waterproof function, to achieve IP65 protection class.





Application



This product is applicable to dusty, outdoor, rainy and snowy operating environment, supporting the use of electric hoists, cranes, outdoor conveyer system, construction machinery, which needs wired electrical remote control system.





Modelmark

  IP65 Industrial Remote Pendant Control Stations Plastic For Crane



Normal Working Conditions



Environment temperature is between +40°C and -25°C

Temperature of 40°C and average humidity 90% is allowable. Can be used in places with rain or snow.

In non-explosive medium; the medium should not have liquid or air that can corrode metal, rubble, or destory insulation.





Major Technical Parameter

Button Marks



Direction marks

IP65 Industrial Remote Pendant Control Stations Plastic For Crane

Double speed marks

IP65 Industrial Remote Pendant Control Stations Plastic For Crane





Size Parameter



Model

Code

Sets

L x B x H

1

2D2. 655. 031

3

310 x 78 x 85

2

2D2. 655. 032

5

370 x 78 x 85

3

2D2. 655. 033

7

430 x 78 x 85

4

2D2. 655. 034

9

490  x 78 x 85

5

2D2. 655. 035

11

550 x 78 x 85

This series confirm to GB14048.5-2001. Proof by CCC, CE, and ISO9001:2000 Quality Mangement System.

IP65 Industrial Remote Pendant Control Stations Plastic For Crane
