|Place of Origin:||CHINA|
|Certification:||ISO9001, CE, CCC|
|Model Number:||Electric Wire Rope Hoist|
|Minimum Order Quantity:||1 Piece/Pieces|
|Packaging Details:||Seaworthy packing|
|Delivery Time:||Within 30 days|
|Payment Terms:||L/C, T/T, D/A, D/P, Western Union, MoneyGram|
|Supply Ability:||10000 Piece/Pieces per Year|
|Maximum Lifting Height::||Max.30m||Maximum Lifting Weight::||80ton|
|Sling Type::||Wire Rope||Power Source::||Electric, 3P, 380V, 50HZ, Other Type Also Available|
|Usage::||Construction Hoist||Model Number::||SH|
|Lift Speed::||20/5m/min||Type::||Trolley Crab|
low headroom trolley hoist,
heavy duty rope hoist
1. Wire Rope Built-Up Trolley Hoist for Double Girder
2. Usage: Heavy duty material handling
3. Stable performance
Detailed Product Description
Heavy Duty Winch Trolley for Metallurgy is typically designed for steel mills, with the application of lifting steel ladle. Usually the classification group can reach A7. We are capable of carry on heavy duty crab trolleys for heavy industries.
Built-up Trolley Hoists are tough and custom designed to meet the service and duty requirements of each individual application. Nante can provide superior quality heavy duty Crab Trolley known for its excellent performance and longer working life. They are designed and manufactured for heavy service. Our robust design utilizes high quality power transmission equipment, controls, and true vertical lift reeving arrangements. The open wind configuration provides for ease of inspection and preventative maintenance.
1. This trolley used in the double rail overhead crane, gantry crane. It is an electric hoisting mechanism on the trolley frame.
2. It can be separated into two big parts: trolley flame,electric hoist, motor, brake, reducer, winding drum.
3. It is widely used in industries, warehouse... as a lifting equipment.
It is wildly used in material handling, metallurgy, mining, oil, petrochemical, chemical, dye, pharmaceutical industry, surrounding protection project, distribution system, port, etc.
Standard features include:
One piece welded structure. Equipment is readily accessible from this upper deck.
Gear case is foot mounted and horizontally split. High-alloy steel mounted on spherical roller bearings.
Standard motor is a foot-mounted motor, customer can choose the brand. Fully flexible geared coupling used at motor output shaft,
Shoe brake is foot mounted, designed for 150% full motor torque. Brake shoes are made from non-asbestos materials and are self-aligning.
Welded steel construction. Machined right and left hand grooving for true vertical lift. Half-depth grooving is provided for improved wire rope life.
Different specification is chosen for hoisting service. Sized for a 5:1 safety factor.
Heavy, one-piece steel welding, sheaves are enclosed and fully guarded. Alloy or carbon steel hook is mounted on a roller thrust bearing for 360º rotation. A spring-loaded safety latch is also provided
Hoist is provided with a weight operated upper limit and a rotary upper & lower geared limit switch.
