5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction

Product Details:

Place of Origin:	CHINA
Brand Name:	NANTE
Certification:	CE
Model Number:	SHA

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Packaging Details:	CARTON
Delivery Time:	1-2weeks
Supply Ability:	100000 sets per year

Contact Now

Detailed Product Description

Max Load Capacity:

100000kg

Sling Type:

Wire Rope

Trolley Speed:

5m/20min

Height:

6/8/9/12/18

High Light:

low headroom trolley hoist

Industrial Electric Hoist

Product Description

The low headroom type electric hoist is of exquisite design, superior performance, novel and beautiful appearance. Also, it meets the latest international certification of DIN, FEM and reaches the technical level of similar products overseas. It is suitable for machining, assembly, warehouse and other places of material handling, especially fit for highly restricted site factory.

Low headroom hoist

Load capacity	FEM	ISO	Height	Speed	Trolley speed	H Size	C Size
(Kg)			(m)	(m/min)	(m/min)	(mm)	(mm)
1000	4m	M7	8/9/12/18	0.8/5.0	5/20	245	385
1260	3m	M6	6/9/12/18	0.8/5.0	5/20	245	385
1600	3m	M6	6/9/12/18	0.8/5.0	5/20	245	385
11100	4m	M7	6/9/12/18	1.3/8.0	5/20	245	385
2000	2m	M5	8/9/12/18	0.8/5.0	5/20	245	385
2000	3m	M6	8/9/12/18	1.3/8.0	5/20	245	385
2500	3m	M6	6/9/12/18	0.8/5.0	5/20	245	385
2500	3m	M6	8/9/12/18	1.0/8.3	5/20	245	385
2500	2m	M5	6/9/12/18	1.3/8.0	5/20	245	385
3200	2m	M5	6/9/12/18	0.8/5.0	5/20	245	385
3200	2m	M5	8/9/12/18	1.0/6.3	5/20	245	385
6000	2m	M5	8/9/12/18	0.8/5.0	5/20	288	496
5000	2m	M5	8/9/12/18	1.8/10	5/20	296	792
6000	3m	M6	8/9/12/18	1.3/8.0	5/20	298	792
6300	1Am	M4	6/9/12/18	0.8/5.0	5/20	266	495
6300	1Am	M4	8/9/12/18	1.3/8.0	5/20	288	496
6300	2m	M5	6/9/12/18	1.3/8.0	5/20	266	495
6300	3m	M6	6/9/12/18	1.0/8.3	5/20	288	496
8000	1Am	M4	8/9/12/18	1.3/8.0	5/20	296	792
11000	3m	M6	8/9/12/18	0.8/5.0	5/20	298	792
10000	1Am	M4	8/9/12/18	1.0/6.3	5/20	298	792
10000	2m	M5	6/9/12/18	0.8/5.0	5/20	296	792
10000	3m	M6	8/9/12/18	0.68/4.0	5/20	298	792
12500	1Am	M4	8/9/12/18	0.8/5.0	5/20	296	792
12500	2m	M5	8/9/12/18	0.6/4.0	5/20	298	792
12500	2m	M5	6/9/12/18	0.6/4.0	5/20	296	792

Load capacity	FEM	ISO	Height	Speed	Trolley speed	H Size	C Size
(Kg)			(m)	(m/min)	(m/min)	(mm)	(mm)
2000	2m	M5	6/9/12/18	0.8/5.0	5/20	230	350
3200	2m	M5	6/9/12/18	0.8/5.0	5/20	230	350
5000	2m	M5	6/9/12/18	0.8/5.0	5/20	230	350
5000	2m	M5	6/9/12/18	0.8/5.0	5/20	230	350
8000	3m	M6	6/9/12/18	0.8/5.0	5/20	540	360
10000	1Am	M4	6/9/12/18	1.0/6.3	5/20	540	360
10000	2m	M5	6/9/12/18	0.8/5.0	5/20	540	360
10000	3m	M6	6/9/12/18	0.66/4.0	5/20	540	360
12500	1Am	M4	6/9/12/18	0.8/5.0	5/20	540	420
12500	1Am	M4	6/9/12/18	1.0/6.3	5/20	540	420
12500	2m	M5	6/9/12/18	0.6/4.0	5/20	540	420
16000	2m	M5	6/9/12/18	0.66/4.0	5/20	640	480
20000	1Am	M4	6/9/12/18	0.66/4.0	5/20	640	480
20000	2m	M5	6/9/12/18	0.53/3.4	5/20	640	480
20000	3m	M6	6/9/12/18	1.0/4.2	5/20	790	620
25000	1Am	M4	6/9/12/18	0.53/3.4	5/20	790	620
25000	2m	M5	6/9/12/18	0.8/3.3	5/20	790	620
25000	2m	M5	6/9/12/18	1.0/4.2	5/20	790	620
32000	2m	M5	6/9/12/18	0.8/3.3	5/20	790	620
32000	2m	M5	6/9/12/18	0~4.9	5/20	895	980
40000	1Am	M4	6/9/12/18	0~4.9	5/20	895	980
50000	2m	M5	6/9/12/18	0~3.2	5/20	895	980
50000	1Am	M4	6/9/12/18	0~4.0	5/20	895	980
63000	1Am	M4	6/9/12/18	0~3.2	5/20	975	1100
63000	2m	M5	6/9/12/18	0~2.4	5/20	975	1100
80000	1Bm	M3	6/9/12/18	0~3.8	5/20	1025	1525
100000	1Bm	M3	6/9/12/18	0~2.1	5/20	1025	1525

Accessories

Trolley drive unit

5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction 0 Trinity of high-performance motor, reduction gearbox and brake. Compact structure, excellent performance. Low energy consumption, low noise and eco-friendly design. Variable frequency control, smooth running, low impact and meeting requirements of a variety of speed. Asbestos-free brake disc and its normal service life can be up to one million times. No-wear design, maintenance-free, long service life.

5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction 1

Rope guide

Light weight, good wear resistance, to reduce the wear of wire rope effectively. Prevent wire rope from skipping and loosing to off-groove, and safety first.

5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction 2 Lifting height limiter

Freely adjustable screw lifting height limiter with high precision, wide adjustment range, safe and reliable. Multiple-contact configurations can effectively achieve the function of transition with low and high speed and the stop during the rise and fall.

Drum

5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction 3 Use the Q345-type seamless steel tube as raw material and process it by numbers of working procedure. Advanced processing methods to ensure concentricity of the drum. The depth of rope groove is in compliance with the FEM standard. High-strength pressing plates and bolts are fastened on the end of the wire rope to ensure the safety of lifting.

5 m / 20 min Trolley Speed Electric Wire Rope Hoist with Modularize Construction 4

Lifting hook group

DIN standard of lifting hook with safety clasp and wire rope sheath Ergonomic design. Forged by the high-strength material of T grade. Accompanied with nondestructive test certification of lifting hook randomly.
