| Place of Origin: | CHINA |
| Brand Name: | NANTE |
| Certification: | ISO9001, CE, CCC |
| Model Number: | HFP52 |
| Minimum Order Quantity: | 100 Meter |
|---|---|
| Packaging Details: | Carton |
| Delivery Time: | 1-2 weeks |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 1000000 meters per year |
| Poles: | 4/7 | Max.current: | 140A |
|---|---|---|---|
| Max.voltage: | 600V | Max. Cross Section: | 35mm2 |
| Self Extinguishing: | Class B1 - No Flaming Particles, Self-extinguishing | Tensile Strength: | 40N/mm ± 10% |
| High Light: | dsl systems,crane busbar system |
||
HFP52 enclosed conductor rail system is a powerail, protected from housing, for indoor and outdoor plants. They are conductor lines in a rigid green PVC housing with different copper cross sections for rated current of 50A-140A.
Type HFP-R: curves for R≥800mm, with factory-mounted flat copper band and screw connectors.
Approved and listed by: CCC, ISO 9001 and CE.
Housing
Color green, PVC housing for 4 conductors. Standard section 4 m.
Other sections are available.
The ground conductor is identified by international color code.
Phase reversing prevented by design of the collector and housing.
Couplings
Through PVC joint caps.
Feed Sets
Line feeds or end feeds.
End caps
The open ends of the powerail are closed by end caps for HFP.
Hangers
Standard brackets for powerail attachment to crane girders are available.
Powerail with sliding and fixpoint hangers.
Standard distance between suspension points for indoor and outdoor installations:1200mm.
Current Collectors
25A current collector is used for conductor bar 50A
40A current collector is used for conductor bar 65A-120A
Application
The ranges of applications of HFP Power Rail Enclosed Conductor System
1. Overhead and elongated tracks for cranes.
2. Electric hoists, electric tools, stacking systems.
3. Electric tools
4. Other applications for supplying power to moving power load.
Design features:
Compact arrangement, corrosion resistance and simple assembly are its essential features.
| Model | Pole No. | Cross section | Max. current | Leakage-distance | Max. voltage | Resistance | Weight |
| HFP52-4-10/50 | 4 | 10 | 50 | 55 | 600 | 1.656 | 2.05 |
| HFP52-7-10/50 | 7 | 10 | 50 | 15 | 600 | 1.656 | 2.32 |
| HFP52-4-15/80 | 4 | 15 | 80 | 55 | 600 | 1.137 | 2.32 |
| HFP52-7-15/80 | 7 | 15 | 80 | 15 | 600 | 1.137 | 2.71 |
| HFP52-4-20/100 | 4 | 20 | 100 | 55 | 600 | 1.011 | 2.47 |
| HFP52-7-20/100 | 7 | 20 | 100 | 15 | 600 | 1.011 | 2.99 |
| HFP52-4-25/120 | 4 | 25 | 120 | 55 | 600 | 0.713 | 2.63 |
| HFP52-7-25/120 | 7 | 25 | 120 | 15 | 600 | 0.713 | 3.27 |
| HFP52-4-35/140 | 4 | 35 | 140 | 55 | 600 | 0.522 | 2.97 |
| HFP52-7-35/140 | 7 | 35 | 140 | 15 | 600 | 0.522 | 3.87 |
