TELECRANE Radio Remote Control Within 100m Control Distance F21 - E2M

TELECRANE Radio Remote Control Within 100m Control Distance F21 - E2M

    • TELECRANE Radio Remote Control Within 100m Control Distance F21 - E2M
    • TELECRANE Radio Remote Control Within 100m Control Distance F21 - E2M
  • TELECRANE Radio Remote Control Within 100m Control Distance F21 - E2M

    Product Details:

    Place of Origin: CHINA
    Brand Name: NANTE
    Certification: ISO, CE, CCC
    Model Number: F21-E2B Series

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Packaging Details: cartons
    Delivery Time: According to customer's requirements
    Payment Terms: L/C, D/A, D/P, T/T, Western Union
    Supply Ability: 500000 Piece/Pieces per Year
    Contact Now
    Detailed Product Description
    Model Number:: F21-E2B Control Distance:: Within 100m
    Speed:: Single
    High Light:

    hoist push button switch

    ,

    Crane Remote Control

    TELECRANE Industrial Radio Remote Controller F21-E2M / Wireless Remote Control for Crane



    Quick Details



    • Model Number:F21-E2B
    • Use: Universal
    • Series: F21-E2B Series
    • Weight: Approx.200g
    • Dimension: 16.5*5.0*5.0cm
    • Shell: Fiberglass
    • Speed: Single speed or double
    • Control Distance: Within 100m



    Packaging & Delivery

    Packaging Details: cartons
    Delivery Detail: According to customer's requirements





    Specifications



    1. Handheld Crane Digital Wireless Remote Control
    2. Singlespeed available







    Button

    6 button, 1 step, 1 EMS





    Receiver
     •  Dimension:  200x85x60mm
     •  Weight: Approx.785~805g (including cable)
     • Receiver Power Supply: 24/48/110/220/380 VAC



    Detailed Product Description



    Auto Frequency Selection

    • Chooses top grade RF 1C with sophisticated design. It provides great performance on radio channel selectivity.
    • Real time frequency changing technology which provides the best operating experience and free from interference.
    • No channel changing required when multiple radio controllers are used at the same time.



    Radio Frequency Filtering

    • A sophisticated Surface Acoustic Wave (SAW filter blocks unwanted radio signal to ensuresmooth radio link.
    • It creates a secure and reliable operation experience even in a complicated industrial working environment



    Reliable Communication

    • F21-E2B, a smart radio controller made by high technology.
    • 100% frequency quality inspection on all radio controllers prior to delivery and ensure frequency tolerance within 0.000001%.



    6-Card (Plug and Play)

    • E-Card works similar to SIM card in the mobile phone.
    • All system data are carried on a small e-Card for easy transfer to a spare system when needed.
    • E-Card is interchangeable between transmitter & receiver. It allows spare transmitter or receiver to resume to work without any downtime.



    6-Card Duplicator

    • The transmitter also acts as e-Card duplicator for data back-up and transfer, i No need to buying COPIER anymore.

    Specifications

    Low power consumption transmitter
    Over 4.3 billions unique ID code available
    Microsoft Windows based software





    Dimension

    1

     • 135 x 55 x 40 mm ( F21-E2S model)

    2

     • 165 x 75 x 45 mm ( F21-E2Bmodel)

    3

     • 165 x 50 x 50 mm ( F21-E2M model)

    4

     • 165 x 75 x 45 mm ( F21-E2B-8model)

    5

     • 160 x 50 x 50 mm ( F21-E2M-8 model)



    Weight
    Approx. 200g (including batteries)



    Receiver

    1

     • Dimension: 200x85x60mm

    2

     • Weight: 785g-805g (including cable)

    3

     • Receiver Power Supply: 24/48/110/220/380 VAC &   12/24V DC



    Application

    The ranges of applications of our industrial radio remote control system

    1. overhead bridge cranes,

    2. gantry crane

    3. beam launcher

    4. monorail hoists,

    5. motorized jib cranes

    6. Other pieces of industrial equipment.



    Budget & Environmental Saving

    Transmitter with extremely low battery power consumption.

    All F21-E2B series transmitters use two AA size batteries.(Carbon Zinc,Alkaline,Ni-MH,Ni-Cd are all acceptable)

    You can also select operating range:

    • It saves and extends battery life.
    • It allows more radio controllers running in a same area.



    Security Enhanced & Anti-Spy

    • Transmitter with its powerful processor, it generates SRC (Security Random Code) radio signal with random coding to prevent spy copying.
    • By integrating hamming coding and CRC (Cyclic Redundancy Check) technology, it provides accuracy in radio data transmission.
    • An unique Non-Repeated security code (ID code), it prevents the error output and improves the operating safety.



    Heavy Duty

    Pushbutton key acts as important role for industrial remote controller.F21-E2B uses a super heavy-duty pushbutton against all severe conditions.



    FREE Powerful Software Program

    Free software consists millions worldwide users' experience.

    F21-E2B software is the total solution for industrial remote controller.

    The software provides great flexibility to meet most of the applications. It allows reprogramming numbers of parameters such as operation function, emission power, and receiver off time, etc.



    Software features

    The software provides great flexibility to meet most of the applications. It allows reprogramming numbers of parameters such as pushbutton function mode (Normal, Toggle, Magnet ON/OFF), Interlock Start Alarm, Selectable Emission Power, and Receiver Auto -Off Time, etc.



    Design features

    1

    • 2~6 commands (Pocket size transmitter : F21-E2B/E2B-8)

    2

     • Low cost for electronic chain hoist/monorail

    3

     • Low power consumption transmitter. 2 AA batteries last up to 4 months

    4

     • Extra shock resistant relay specially for mobile devices .(DC model only)

    5

     • Over 4.3 billions unique ID code available.

    6

     • Temperature range -35°C ~ +85°C

    7

     • Enclosure protection class IP 65

    8

     • Microsoft Windows based software for easy customize configuration

    9

     • Structure : Glass-Fiber
