Universal Electric Hoist With Wireless Remote Single Speed F21 - E2B - 8

Radio Remote Controls have become a key element within a modern working context where safety, productivity, freedom of movement has a continuously increasing importance. Industrial radio controllers are consequently for time saving and risk reduction working instruments.

• Durable nylon-fiber housing for extra shock resistance.
• Low power consumption with 2 AA batteries (last up to 2 months in normal operation).
• Operating range up to 100 meters.
• Programmable function setting through Windows-based software.
• Economic efficiency, ease of operation.
• Pre-wiring standard cable making wiring procedures easier.
• 100% compatible components reducing stock of spare part.

Safety features

• 4.3 billion unique ID code
• Hamming code
• enhanced watch-dog circuit

Application
Single or double speed traveling crane and other industrial remote control application with less than 12 contacts.
Design features
Flexible design
Computor interface to set internal functions
Safety key switch to prevent from unauthorized user
Durable nylon-fiber housing for extra shock resistance

Auto Frequency Selection

• Chooses top grade RF 1C with sophisticated design. It provides great performance on radio channel selectivity.
• Real time frequency changing technology which provides the best operating experience and free from interference.
• No channel changing required when multiple radio controllers are used at the same time.

Radio Frequency Filtering

• A sophisticated Surface Acoustic Wave (SAW filter blocks unwanted radio signal to ensuresmooth radio link.
• It creates a secure and reliable operation experience even in a complicated industrial working environment

Reliable Communication

• F21-E2B, a smart radio controller made by high technology.
• 100% frequency quality inspection on all radio controllers prior to delivery and ensure frequency tolerance within 0.000001%.

6-Card (Plug and Play)

• E-Card works similar to SIM card in the mobile phone.
• All system data are carried on a small e-Card for easy transfer to a spare system when needed.
• E-Card is interchangeable between transmitter & receiver. It allows spare transmitter or receiver to resume to work without any downtime.

6-Card Duplicator

• The transmitter also acts as e-Card duplicator for data back-up and transfer, i No need to buying COPIER anymore.

Budget & Environmental Saving

Transmitter with extremely low battery power consumption.

All F21-E2B series transmitters use two AA size batteries.(Carbon Zinc,Alkaline,Ni-MH,Ni-Cd are all acceptable)

You can also select operating range:

• It saves and extends battery life.
• It allows more radio controllers running in a same area.

Security Enhanced & Anti-Spy

• Transmitter with its powerful processor, it generates SRC (Security Random Code) radio signal with random coding to prevent spy copying.
• By integrating hamming coding and CRC (Cyclic Redundancy Check) technology, it provides accuracy in radio data transmission.
• An unique Non-Repeated security code (ID code), it prevents the error output and improves the operating safety.

Heavy Duty

Pushbutton key acts as important role for industrial remote controller.F21-E2B uses a super heavy-duty pushbutton against all severe conditions.

FREE Powerful Software Program

Free software consists millions worldwide users' experience.

F21-E2B software is the total solution for industrial remote controller.

The software provides great flexibility to meet most of the applications. It allows reprogramming numbers of parameters such as operation function, emission power, and receiver off time, etc.

Software features

The software provides great flexibility to meet most of the applications. It allows reprogramming numbers of parameters such as pushbutton function mode (Normal, Toggle, Magnet ON/OFF), Interlock Start Alarm, Selectable Emission Power, and Receiver Auto -Off Time, etc.
