| Place of Origin: | CHINA |
| Brand Name: | NANTE |
| Certification: | CE |
| Model Number: | HFP56 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | carton or wooden case |
| Delivery Time: | within 10days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10000000 pcs per Year |
| Application:: | Electric Tools | Pole No.:: | 4poles |
|---|---|---|---|
| Tensile Strength:: | 40N/mm2±10% | Max. Voltage:: | 600v |
| Current:: | 35A To 240A | Support Spacing:: | For Straight Runs 1.2m |
| Highlight: | dsl systems,crane busbar system |
||
Product Description
Powerail Enclosed conductor rail system is a powerail,protected from contact(IP 23).For indoor and outdoor plants. They are conductor lines in a rigid green PVC housing with different copper cross sections for rated currents of 35- 240A.
The current collectors,running in ball bearing, are guided by the housing.
The main is transferred by spring-stored carbon brushes.
Type HFP-P: not include Sealing strip, with factory-mounted flat copper band and bolted-operated plug connectors.
Type HFP-R: Curves for R >800mm, with factory-mounted flat copper band and screw connectors.
Approved and listed by: CCC,ISO9001 and CE.
Technical data HFP56copper conductor rail current collector insulated
| Electrical properties | Mechanical properties | ||
| Max.current | 240A | Flexible strength | 75N/mm2 ± 10% |
| Max.voltage | 660V | Tensile strength | 40N/mm2 ± 10% |
| Dielectric strength | 30-40KV/mm | Temperature range | |
| Spec.resistance | 5*1015 Ohm*cm | Standard Housing | -20℃ up to +70℃ |
| Surface resisitance | 1013Ohm*cm | High Temp. Housing | -10℃ up to +115℃ |
| Leakage resisitance | CTI600-2.7 | Low Temp. Housing | -40℃ up to +80℃ |
| Combustibility | |||
| Flame retardant | Class B1-no flaming particles,self-extinguishing | ||
| Self extinguishing | Class B1-no flaming particles,self-extinguishing | ||
Detailed Products HFP56 copper conductor rail current collector insulated
Name:HFP56copper conductor rail current collector insulated Conductor code: HFP56-4
Length: 4m is standard length, other lengths are available,but not be exceeding 6m.
| Type | Poles | Max.current(A) | Max.valtage(V) | Resistance | Weight(kg) |
| HFP56-4/35 | 4 | 35 | 660 | 1.944 | 2.09 |
| HFP56-4/50 | 4 | 50 | 660 | 1.656 | 2.16 |
| HFP56-4/65 | 4 | 65 | 660 | 1.321 | 2.23 |
| HFP56-4/80 | 4 | 80 | 660 | 1.137 | 2.30 |
| HFP56-4/100 | 4 | 100 | 660 | 1.011 | 2.43 |
| HFP56-4/120 | 4 | 120 | 660 | 0.713 | 2.56 |
| HFP56-4/140 | 4 | 140 | 660 | 0.522 | 2.95 |
| HFP56-4/170 | 4 | 170 | 660 | 0.337 | 3.25 |
| HFP56-4/210 | 4 | 210 | 660 | 0.265 | 3.85 |
| HFP56-4/240 | 4 | 240 | 660 | 0.223 | 4.16 |
Collector for 4 poles Powerail
| Type | Weight(kg) | Poles | Power rating |
| HFP56-4/25 | 0.65 | 4 | 25A |
| HFP56-4/40 | 0.70 | 4 | 40A |
| HFP56-4/60 | 1.35 | 4 | 60A |
| HFP56-4/80 | 1.30 | 4 | 80A |
| HFP56R-4/25 | 0.50 | 4 | 25A |
| HFP56R-4/40 | 0.60 | 4 | 40A |
| HFP56-3/60 | 0.90 | 4 | 60A |
| HFP56-3/80 | 1.05 | 4 | 80A |
